Operation of Ship Loading Spouts
At the beginning of ship loading, spout is lowered towards the flatbed of ship and stops at the bottom. Flexible dust skirt located at the bottom side of spout keeps the dust content inside the loading area. During material discharge, spout dust skirt provides a closed containment for dust. Dust collector vacuums any fugitive dust in the region and prevents dust emission to surrounding. Collected dust is then sent back to the product stream continuously and no material is wasted during loading. Built in level sensors monitor the product level below the loading spout dust skirt. When the material level increases, spout is retracted upwards automatically and it maintains a space to let the material flow rapidly. After ship loading is finished, product discharge valve above the loading spout is closed. System waits for few seconds to complete product flow and to collect remaining dust by dust collector. Loading spout automatically retracts to the top position afterwards.
- Dust free loading
- Dust free working region, prevention of dust pollution, ensure port and environmental safety.
- Suitable for different bulk solids conveying and storage systems
- Loading is possible from different equipment like silo, hopper, screw feeder, conveyors etc.
- Extensive range of models are available for wide range of needs
- Built in flexible dust skirt to prevent dust emission outside of the loading region.
- No spillage and no product waste
- Food grade loading spouts are available
- Simple operation
- Easy maintenance
Cement, fly ash, mining minerals, calcium carbonate, pvc, plastic pellets, plastic powders, alumina, bentonite, bauxite, coal, cement clinker, gypsium, kaolin, limestone, marble powder, soda ash, quartz, urea, sodium sulphate, wheat, flour, animal feed, seed, corn, rice, sugar, salt and similar powdered and granular dry bulk solids.
Extensive range of loading spouts are available for wide range of applications. Open truck loading, bulk tanker filling, stockpile loading and bulk ship loading spouts provide dust free outloading of bulk materials for industrial applications.
Bulk solid transfer equipment are used to transfer powdered and granular materials to loading spouts. Bulk materials are discharged from silos, hoppers, production lines with these transfer and conveying equipment.
Loading spouts and bulk solid discharge systems can be provided with extensive range of optional components and accessories for different application needs. Proper selection of accessories is essential for efficient and dust-free loading.
